Inspection Solutions for Electronics Manufacturing
Optical and digital inspection systems for electronics manufacturing, from PCB assembly and solder inspection to quality control and documentation.
- PCB & Solder Joint Inspection
- Rework & Repair
- Conformal Coating Inspection
- Documentation & Collaboration
- Incoming Inspection & QC
- Trusted for Over 60 Years
Systems for Your Electronics Manufacturing Needs
Vision Engineering’s inspection microscopes are used around the world in electronics manufacturing, where high image quality and magnification are required. With more than 60 years of industry experience, we understand the challenges you face when it comes to quality control and offer solutions for your specific applications, from PCB assembly and solder joint inspection to conformal coating verification, rework on fine pitch components, and documentation across the production line.
STEREO INSPECTION MICROSCOPES
Vision Engineering’s stereo microscopes deliver depth perception and operator comfort for hands-on inspection, rework, and assembly tasks in electronics manufacturing. Patented eyepiece-less Dynascope® technology allows natural head positioning, reducing fatigue during extended inspection sessions involving fine pitch components, BGAs, and micro components on PCBs.
Bench Magnifiers
Industrial illuminated magnifiers using LUXO arm technology, available in ESD-safe, UV, and White/UV models. Used for workstation-level inspection of PCBs and components, ESD-safe inspection in electronics assembly areas, UV inspection of conformal coatings, and rework and solder touch-up under magnification. All magnifiers backed by a 5-year warranty.
Mantis
Eyepiece-less stereo microscope with a rotating turret holding up to 3 objectives for quick magnification changes. Five illumination options including UV for conformal coating inspection. Used for PCB solder joint inspection, component placement verification, and incoming goods inspection across electronics production lines
Lynx EVO
Eyepiece-less stereo zoom microscope with patented Dynascope® optics. Long working distance and iris control for depth of field. Ideal for PCB rework on fine pitch components and BGAs, detailed inspection of micro components, and solder joint verification with natural hand-eye coordination.
GET PRICING OR BOOK A DEMONSTRATION TODAY
(860) 355 3776
DIGITAL INSPECTION MICROSCOPES
Vision Engineering’s digital microscopes provide on-screen viewing, image capture, and documentation for electronics quality assurance and traceability. From full HD imaging with zero video latency to glasses-free 3D viewing with remote sharing, these systems support collaborative review, defect documentation, and archival of inspection records throughout the production line.
ProteQ VISO
Digital stereo 3D viewer providing magnified 3D images without special glasses or eyepieces. Twin HD stereo cameras at 60fps with eye-tracking deliver natural 3D viewing for precision workflows. Used for 3D PCB inspection with genuine depth perception, remote collaboration with suppliers and engineering, rework under 3D view, and training and peer-to-peer review.
EVO Cam HALO
4K Ultra HD digital microscope with intelligent lighting and Auto Lens ID, ensuring the correct magnification is displayed at all times. 4K video streaming and recording via PC or capture device for high-detail electronics inspection and documentation requirements.
EVO Cam II Series
Full HD digital microscope with 1080p/60fps output and zero video latency. Features focus stacking, image overlay, on-board measurement, and WiFi transfer. No PC required for capture. Used for documentation of solder joint quality, PCB defect capture and annotation, and training and process verification via live display.
EVO Cam ICON
Cost-effective HD digital microscope with 1080p/60fps output. HDMI and USB 3.0 outputs enable live viewing and image capture without a PC. A versatile imaging solution for electronics inspection tasks where digital documentation is needed without the full EVO Cam II feature set.
GET PRICING OR BOOK A DEMONSTRATION TODAY
(860) 355 3776
MEASUREMENT & VISION SYSTEMS
Vision Engineering’s measurement systems combine video and optical technologies for accurate, traceable measurement in electronics manufacturing. Repeatable dimensional verification supports inspection of features such as connector pins, solder pads, component spacing, and small PCB features. Automated measurement routines support repeat inspection of consistent layouts while maintaining reliable measurement performance across operators and shifts.
Swift Series
Non-contact measurement systems available in multiple configurations: Swift PRO Cam for video measurement, Swift PRO Elite for optical measurement, and Swift PRO Duo for combined video and optical. Designed for shop-floor measurement of small electronic components, connectors, and machined parts with non-contact accuracy.
TVM Series
Place-and-measure field-of-view video measurement system delivering rapid measurements with a click. Available in multiple field-of-view sizes from 20mm to 200mm. Used as a digital profile projector or video measurement system for Go/No Go results with full geometric tolerancing on the electronics production floor.
LVC Series
Large capacity CNC video measurement system with 400mm x 300mm x 200mm measuring range, 5MP and 6.4MP camera options, and motorized stage with motorized zoom lens. Fully automated measurement for high-precision electronics components and PCBs, suited for measuring multiple small components quickly and accurately.
GET PRICING OR BOOK A DEMONSTRATION TODAY
(860) 355 3776
Vision Engineering is a leading-edge manufacturer of patented optical and digital stereo microscopes and measuring systems.
For over 60 years Vision Engineering has improved the inspection process through its industrial bench magnifiers, optical microscopy products and measurement systems. Vision Engineering systems are known for improving product quality and production efficiency through innovative technologies, quality systems, and ergonomic design.
Our unique patented products have benefitted manufacturing companies globally by reducing man-hours and material wastage and ensuring quality and conformance to desired specifications.
Contact us to find a system to maintain quality in your manufacturing process.
